NAND-gate Latch
NAND逻辑门锁存器
The time sequence at right shows the conditions under which the set and reset inputs cause a state change, and when they don't. 右边的时间序列显示了集电极开路输入在引起状态变化的条件以及不引起状态变化的情况。
The concept of a "latch" circuit is important to creating memory devices. The function of such a circuit is to "latch" the value created by the input signal to the device and hold that value until some other signal changes it. “锁存器”电路的概念对于制造存储器设备至关重要。此类电路的功能是将输入信号产生的值锁存到设备中，并在其他信号改变之前保持该值。
|
|
| Set-reset Flip-flop
置位-复位翻转器 | NOR-gate Latch
NOR门锁存器 |
| To Clocked Version
时钟版本 | NAND Gate
与非门 |
| Application in D Flip-flop
在D触发器中的应用 |
