UJT Relaxation Oscillator

The negative resistance characteristic of the unijunction transistor makes possible its use as an oscillator. 负电阻特性使单结晶体管得以用于振荡器。 after Diefenderfer & Holton p.223 见Diefenderfer & Holton第223页

Relaxation Oscillator Concept

The concept of a relaxation oscillator is illustrated by this flasher circuit where a battery repeatedly charges a capacitor to the firing threshold of a bulb, so that the bulb flashes at a steady rate.

When the capacitor is charged to the firing threshold of the bulb, the bulb begins to conduct and the capacitor discharges, dumping its energy to the bulb, flashing the bulb. After the flash, the battery begins charging the capacitor again.

A relaxation oscillator is a repeating circuit (like the flasher circuit illustrated above) which achieves its repetitive behavior from the charging of a capacitor to some event threshold. The event discharges the capacitor, and its recharge time determines the repetition time of the events. In the simple flasher circuit, a battery charges the capacitor through a resistor, so that the values of the resistor and the capacitor (time constant) determine the flashing rate. The flashing rate can be increased by decreasing the value of the resistance.

One of the reasons for the importance of the relaxation oscillator concept is that some neural systems act like relaxation oscillators. For example, the bundle of nerve fibers called the SA node (sino-atrial node) in the upper right hand part of the heart acts as the natural pacemaker of the heart, firing at a regular rate. The rate of this oscillator is variable, and can be increased in response to exertion or alarm. While this is an attactive simple picture of the hearts repeating electrical pattern, physiologists caution that this is a gross oversimplification of the electrical action of the heart. The heart's electrical system has several active components, and even the heart's muscle cells are electrically active and excitable in a different way than other muscle cells in the body.

Other nerve cells recharge like a capacitor, but then wait for some kind of stimulus to fire. In response to some kind of trauma, it might be that the firing threshold is lowered enough to "self fire" and act as a relaxation oscillator. This is an intriquing possibility for explaining the ringing in the ears after a loud concert.
