Developing Kepler's Law of Orbits

Law of Orbits: two masses orbiting each other in bound orbits under the influence of the law of gravity will follow elliptical orbits about the center of mass of the two-body system.

The motion of a binary system can be described relative to the center of mass of the system. The vector distance between the two masses is 二体系统的运动可以相对于系统的质心来描述。两质量之间的矢量距离是 and the motion of one of the masses relative to the other uses the concept of reduced mass: 并且一个质量相对于另一个质量的运动使用了约化质量的概念：

The individual vector coordinates of the masses can be expressed in terms of the reduced mass:

Kepler's Laws depend upon the principle of conservation of angular momentum, and since these are inherently vector quantities, the angular momentum is expressed in terms of vector products. The angular momentum of the two body system can be expressed in terms of their relative velocity and the reduced mass of the system. Starting with the individual angular momenta, the angular momentum of the system L can be expressed as follows:

This provides the necessary framework for showing that angular momentum is conserved for an orbiting planet or a member of a binary star system. This is done by showing that the derivative of the angular momentum is zero for the case where the force of attraction acts along the line between the two bodies. This requires the expression for the derivative of a product of functions. Using the expression for angular momentum L obtained above:

This establishes the fact that the angular momentum L is conserved for any system of two orbiting masses acted upon by a central force. The conservation of angular momentum leads to both Kepler's Law of Orbits and Law of Areas. 这确立了这样一个事实：对于任何由中心力作用的两个轨道质量系统，角动量 L 是守恒的。角动量的守恒导致了开普勒的轨道定律和面积定律。

The orbit of one of the masses in a binary system can be described as the motion of the reduced mass around a point at relative distance r where the total mass is placed. The magnitude of r is the same as the relative distance r in the development above. 二体系统中一个质量的轨道可以描述为约化质量围绕一个点的运动，该点位于相对距离r处，总质量被放置在该点。r的大小与上述发展中的相对距离r相同。

The determination that the motion of both masses in a bound binary system execute elliptical orbits about a focus point at the center of mass of the system requires the analysis of the force and angular momentum of the system. The angular momentum L of the system can be expressed as

In this expression, the unit vectors in the r direction have been introduced because both the magnitude of r and its direction can change. Note that one term drops out of the vector product expression because it contains the vector product of the unit vector and itself and is therefore zero.

The acceleration of the reduced mass is given by

where M is the total mass of the system. As a strategy for obtaining an expression for r, the following evaluation is made:

where the facts that the scalar product of two unit vectors is equal to 1 and the scalar product of the unit vector and its derivative is equal to 0 are used in addition to the vector identity.

Continuing a strategy directed toward finding an expression for radius vector r in terms of the angular momentum, the above expression is modified so that it is an equality of two derivatives. The rule for differentiation of a product is used along with the fact that dL/dt=0 (conservation of angular momentum).

Now integrating the two differential quantities gives

where we can argue that the vector constant of integration D must be in the plane of the orbit since the other two quantities lie in that plane. To introduce the radius vector r into this expression the following procedure with a vector identity is followed.

Using the final expression for angular momentum L from above, this can be put in the form

The final step in showing that this is the expression for a conic section orbit is to define e=D/GMμ so that the radius r becomes

This form for the equation of a conic section expresses it in terms of the angular momentum L, the eccentricity e, and the angle θ measured from the perihelion. For e<1 this is the form of an ellipse and can be expressed in terms of the semimajor axis a.

Setting these two expressions equal to each other gives an expression for the angular momentum L

For a bound binary orbit, each object will follow an elliptical orbit about the center of mass of the system. The center of mass will be at one focus of each ellipse. 对于束缚二体轨道，每个物体将围绕系统的质心做椭圆轨道运动。质心将位于每个椭圆的一个焦点上。

Developing Kepler's Law of Areas

Law of Areas: Considering the area of an elliptical orbit, an infinitesemal area element can be expressed as Integrating over r from the focus outward gives So the time rate of change of the area swept out is 面积定律：考虑椭圆轨道的面积，一个微小的面积元素可以表示为。对r从焦点向外积分得到，因此扫过的面积随时间的变化率是

The velocity is in the plane of the ellipse and can be divided into radial and angular components:

Development of The Law of Periods

Law of Periods: The Law of Areas shows that the rate of change of area is proportional to the angular momentum L, and the development of the Law of Orbits showed that the angular momentum is a constant for the orbit. That rate of change of area can be integrated over time to obtain the period P.

This establishes Kepler's Law of Periods.

In this form it is useful for calculation of the orbital period of moons or other binary orbits like those of binary stars.
