Band Theory of Solids

固体的能带理论

A useful way to visualize the difference between conductors, insulators and semiconductors is to plot the available energies for electrons in the materials. Instead of having discrete energies as in the case of free atoms, the available energy states form bands. Crucial to the conduction process is whether or not there are electrons in the conduction band. In insulators the electrons in the valence band are separated by a large gap from the conduction band, in conductors like metals the valence band overlaps the conduction band, and in semiconductors there is a small enough gap between the valence and conduction bands that thermal or other excitations can bridge the gap. With such a small gap, the presence of a small percentage of a doping material can increase conductivity dramatically.

一种有助于理解导体、绝缘体和半导体之间差异的方法是绘制材料中电子的可用能量。与自由原子的情况不同,材料中的可用能量状态形成带。传导过程的关键在于传导带中是否存在电子。在绝缘体中,价带中的电子与传导带之间有较大的能量间隙;在导体中,如金属,价带与传导带重叠;而在半导体中,价带与传导带之间的间隙很小,热或其它激发可以跨越这个间隙。由于这个间隙很小,少量掺杂剂的加入就可以显著提高导电性。

An important parameter in the band theory is the Fermi level, the top of the available electron energy levels at low temperatures. The position of the Fermi level with the relation to the conduction band is a crucial factor in determining electrical properties.

带理论中的一个重要参数是费米电平,即在低温下电子可利用能级的顶部。费米电平与导带之间的位置是决定电学性质的关键因素。
Closer look at bands
更深入地观察能带
Band gap dependence on interatomic spacing
带隙与原子间距的依赖关系
Index

Semiconductor concepts

Semiconductors for electronics
索引 半导体概念 半导体在电子学中的应用

HyperPhysics***** Condensed Matter
HyperPhysics ***** 凝聚态物理
R Nave
Go Back
返回





Energy Bands for Solids

固体的能带
Click on any part of the illustration for further information.
点击示意图的任何部分以获取更多信息。


Band theory
能带理论
More details on diagram
关于图的更多细节
Index

Semiconductor concepts

Semiconductors for electronics
索引 半导体概念 半导体在电子学中的应用

HyperPhysics***** Condensed Matter
HyperPhysics ***** 凝聚态物理
R Nave
Go Back
返回





Energy Bands Comments

能带注释
Band gap dependence on interatomic spacing
带隙与原子间距的依赖关系
Index

Semiconductor concepts

Semiconductors for electronics
索引 半导体概念 半导体在电子学中的应用

HyperPhysics***** Condensed Matter
HyperPhysics ***** 凝聚态物理
R Nave
Go Back
返回





Insulator Energy Bands

绝缘体能带

Most solid substances are insulators, and in terms of the band theory of solids this implies that there is a large forbidden gap between the energies of the valence electrons and the energy at which the electrons can move freely through the material (the conduction band).

大多数固体是绝缘体,在固体的带理论中,这表明价电子的能量与电子可以在材料中自由移动的能量(导带)之间的禁带很大。

Glass is an insulating material which may be transparent to visible light for reasons closely correlated with its nature as an electrical insulator. The visible light photons do not have enough quantum energy to bridge the band gap and get the electrons up to an available energy level in the conduction band. The visible properties of glass can also give some insight into the effects of "doping" on the properties of solids. A very small percentage of impurity atoms in the glass can give it color by providing specific available energy levels which absorb certain colors of visible light. The ruby mineral (corundum) is aluminum oxide with a small amount (about 0.05%) of chromium which gives it its characteristic pink or red color by absorbing green and blue light.

玻璃是一种绝缘材料,它对可见光透明的原因与其作为电绝缘体的性质密切相关。可见光的光子能量不足以跨越带隙,从而将电子提升到导带中的可用能级。玻璃的可见特性也可以提供一些关于“掺杂”对固体性质影响的见解。玻璃中极少量的杂质原子可以赋予它颜色,这些杂质原子提供了特定的可用能级,能够吸收特定波长的可见光。红宝石矿物(刚玉)是铝氧化物,其中含有约0.05%的铬,这种铬赋予了红宝石其特征的粉红色或红色,通过吸收绿色和蓝色光实现。

While the doping of insulators can dramatically change their optical properties, it is not enough to overcome the large band gap to make them good conductors of electricity. However, the doping of semiconductors has a much more dramatic effect on their electrical conductivity and is the basis for solid state electronics.

尽管对绝缘体掺杂可以显著改变其光学性质,但不足以克服较大的带隙使其成为良好的电导体。然而,对半导体的掺杂对其电导率影响更为显著,并构成了固体电子学的基础。
Index

Semiconductor concepts

Semiconductors for electronics
索引 半导体概念 半导体在电子学中的应用

HyperPhysics***** Condensed Matter
HyperPhysics ***** 凝聚态物理
R Nave
Go Back
返回





Semiconductor Energy Bands

半导体能带

For intrinsic semiconductors like silicon and germanium, the Fermi level is essentially halfway between the valence and conduction bands. Although no conduction occurs at 0 K, at higher temperatures a finite number of electrons can reach the conduction band and provide some current. In doped semiconductors, extra energy levels are added.

对于像硅和锗这样的本征半导体,费米能级基本上位于价带和导带之间。尽管在0 K时没有导电现象,但在较高温度下,一些电子可以到达导带并提供一定的电流。在掺杂半导体中,会额外加入一些能级。

The increase in conductivity with temperature can be modeled in terms of the Fermi function, which allows one to calculate the population of the conduction band.

导电性随温度的增加可以用费米函数来建模,这使得能够计算导带中载流子的数量。
Band theory of solids
固体的能带理论
Semiconductor bandgaps
半导体带隙
Show the effect of impurities
显示杂质的影响
Silicon energy bands
硅的能带
Germanium energy bands
锗的能量带
Index

Semiconductor concepts

Semiconductors for electronics
索引 半导体概念 半导体在电子学中的应用

HyperPhysics***** Condensed Matter
HyperPhysics ***** 凝聚态物理
R Nave
Go Back
返回





Conductor Energy Bands

导体能带

In terms of the band theory of solids, metals are unique as good conductors of electricity. This can be seen to be a result of their valence electrons being essentially free. In the band theory, this is depicted as an overlap of the valence band and the conduction band so that at least a fraction of the valence electrons can move through the material.

根据固体的带理论,金属是唯一的良好导体。这可以解释为它们的价电子基本上是自由的。在带理论中,这被描绘为价带和导带的重叠,使得至少一部分价电子能够通过材料移动。
Index

Semiconductor concepts

Semiconductors for electronics
索引 半导体概念 半导体在电子学中的应用

HyperPhysics***** Condensed Matter
HyperPhysics ***** 凝聚态物理
R Nave
Go Back
返回





Silicon Energy Bands

硅的能量带
At finite temperatures, the number of electrons which reach the conduction band and contribute to current can be modeled by the Fermi function. That current is small compared to that in doped semiconductors under the same conditions.

Compare to germanium

与锗比较
在有限温度下,能够到达导带并参与导电的电子数量可以用费米函数来建模。在相同条件下,这种电流远小于掺杂半导体中的电流。
Index

Semiconductor concepts

Semiconductors for electronics
索引 半导体概念 半导体在电子学中的应用

HyperPhysics***** Condensed Matter
HyperPhysics ***** 凝聚态物理
R Nave
Go Back
返回





Germanium Energy Bands

锗的能带
At finite temperatures, the number of electrons which reach the conduction band and contribute to current can be modeled by the Fermi function. That current is small compared to that in doped semiconductors under the same conditions.

Compare to silicon

与硅相比
在有限温度下,能够到达导带并参与导电的电子数量可以用费米函数来建模。在相同条件下,这种电流远小于掺杂半导体中的电流。
